| PV Input | 3KS-L1 | 3.6KS-L1 | 4KS-L1 | 4.6KS-L1 | 5KS-L1 | 6KS-L1 |
|---|---|---|---|---|---|---|
| Max. Input Power (Wp) | 6000 | 7200 | 7200 | 8000 | 8000 | 9000 |
| Max. PV Input Voltage (V) | 600 | |||||
| MPPT Voltage Range (V) | 80–550 | |||||
| Full Load MPPT Voltage Range (V) | 350–500 | |||||
| Normal PV Input Voltage (V) | 360 | |||||
| Startup Voltage (V) | 95 | |||||
| Max. Input Current per MPPT (A) | 18 | |||||
| Max. Short Current per MPPT (A) | 22 | |||||
| No. of MPP Tracker / No. of PV String | 2 / 1 | |||||
| Battery Port | ||||||
| Max. Charging/Discharging Current (A) | 75 | 85 | 85 | 100 | 100 | 100 |
| Max. Charging Voltage (V) | 60 | |||||
| Nominal Battery Voltage (V) | 51.2 | |||||
| Battery Voltage Range (V) | 42 – 58 | |||||
| Battery Type | Li-ion / Lead-acid | |||||
| ON Grid | ||||||
| Nominal Output Power (W) | 3000 | 3600 | 4000 | 4600 | 5000 | 6000 |
| Max. Output Current (A) | 13.6 | 16.4 | 18.2 | 20.8 | 22.7 | 27.2 |
| Max. Input Current (A) | 16.4 | 22.7 | 22.7 | 27.2 | 27.2 | 27.2 |
| Grid Voltage (V) | 220/230/240 (184–276) | |||||
| Nominal Grid Frequency (Hz) | 50 / 60 (45–65) | |||||
| Power Factor | 1 (0.8 leading – 0.8 lagging, adjustable) | |||||
| Current THD (%) | < 3 | |||||
| Off-grid Output | ||||||
| Nominal Output Power (W) | 3000 | 3600 | 4000 | 4600 | 5000 | 6000 |
| Nominal Output Current (A) | 13.6 | 16.4 | 18.2 | 20.8 | 22.7 | 27.2 |
| Nominal Voltage (V) | 220/230/240 | |||||
| Nominal Frequency (Hz) | 50/60 | |||||
| Output THDu | less than 2% | |||||
| Switching Time (s) | less than 10ms | |||||
| Efficiency | ||||||
| Max. Efficiency (%) | 97.5 | 97.5 | 97.8 | 97.8 | 98.0 | 98.0 |
| European Efficiency (%) | 97.2 | 97.2 | 97.3 | 97.3 | 97.5 | 97.5 |
| Max. Battery Charging/Discharging Efficiency (%) | 95.2 | |||||
| Protection | ||||||
| PV Insulation Resistance Detection | Yes | |||||
| Residual Current Monitoring | Yes | |||||
| Anti-islanding Protection | Yes | |||||
| AC Short Circuit Protection | Yes | |||||
| AC Overload Protection | Yes | |||||
| AC Overvoltage Protection Level | III | |||||
| DC Overvoltage Protection Level | II | |||||
| Surge Protection | Yes | |||||
| Reverse Polarity Protection (PV & BAT) | Yes | |||||
| General Data | ||||||
| Dimensions (W x H x D, mm) | 500 × 470 × 180 | |||||
| Weight (kg) | 21 | |||||
| Topology | Transformerless | |||||
| Cooling | Natural Cooling | |||||
| Noise | less than 25 dB(A) | |||||
| Operating Temperature Range (°C) | -25 to 60 | |||||
| Operating Altitude (m) | < 4000 | |||||
| Ingress Protection | IP65 | |||||
| Standby Consumption (W) | < 10 | |||||
| Mounting | Wall Bracket | |||||
| Communication Port | RS485 / CAN / DRED / Dry Contact / Parallel | |||||
| Display & Monitoring | LED / APP / WiFi / 4G / Bluetooth | |||||
| Certification & Approvals | CE-LVD, CE-EMC, BIS, IEC 61683, IEC 62116, IEC 61727, EN 50549-1 | |||||
